Showing 1–9 of 13 results
-
€10,000.00
| Part Number: 1283-00
Features:
- Aluminum Reinforced Fixed Position Pod Drive, Robust Design
- Recommended for Sailboats up to 12 tons
- Diesel Inboard Equivalent: 25 HP
- Forward/Neutral/Reverse drive
- Onboard Computer and Display with GPS-Calculated range and runtime
- When used in combination with a Torqeedo Power Battery you get a Real Time Display of Speed, Input Power, Exact Battery Status and Remaining Range
- Operates with Lithium or AGM/Lead-Gel Batteries (Sold Separately)
- TorqLink Data Interface – enables fast data exchange between TorqLink components without gateway
Specifications:
- Engine Type: Electric – 48V
- Remote (Remote Throttle Not Included)
- Weight: 73.9 lbs
- Power Cable: 4.5 Meters
- Diesel Inboard Equivalent: 25 HP (Propulsive Power)
- Diesel Inboard Equivalent: 25 HP (Thrust)
- Propulsive Power inW: 6,720
- Static thrust: Up to 405 lbs
- Torqeedo static thrust measurement is based on internationally accepted ISO standards. Static thrust figures for conventional trolling motors are typically measured differently, which results in higher values. To compare Torqeedo static thrust data with conventional trolling motors, add approximately 50% to the Torqeedo static thrust values
- RPM Range: Variable to 1,400
- Standard Propeller: 5 Blade fiberglass reinforced polyamide
- v15/p10k
- Slower Speed
- Greater Thrust
- Waterproof (IPx9K outside the hull when completely assembled)
- Requires 48V DC
- Can be powered by (2 or more) Torqeedo Power 48-5000 batteries
- External Battery(s) are not included with this model
- This model does not use an Internal battery
- Optional Folding Propeller (Sold Separately)
- Factory Warranty: 2 years. Warranty Begins on Date of Purchase.
-
€3,315.79
Description
Features:
- Aluminum Reinforced Fixed Position Pod Drive, Robust Design
- Recommended for Sailboats up to 3 tons
- Gas Outboard Equivalent: 6 HP
- Forward/Neutral/Reverse drive
- Onboard Computer and Display with GPS-Calculated range and runtime
- Operates with Lithium or AGM/Lead-Gel Batteries (Sold Separately)
Specifications:
- Engine Type: Electric – 24V
- Remote (Remote Throttle Not Included)
- Weight: 28.2 lbs
- Power Cable: 4.4 Meters
- Gas Outboard Equivalent: 6 HP (Propulsive Power)
- Gas Outboard Equivalent: 8 HP (Thrust)
- Propulsive Power in Watts: 1,530
- Static thrust: 142 lbs
- Torqeedo static thrust measurement is based on internationally accepted ISO standards. Static thrust figures for conventional trolling motors are typically measured differently, which results in higher values. To compare Torqeedo static thrust data with conventional trolling motors, add approximately 50% to the Torqeedo static thrust values
- RPM Range: Variable to 1,100
- Standard Propeller: 3 Blade fiberglass reinforced polyamide
- Waterproof (IPx9K outside the hull when completely assembled)
- Requires 24V DC
- Can be powered by (1) Torqeedo Power 28-3500
- External Battery(s) are not included with this model
- This model does not use an Internal battery
- Optional Folding Propeller (Sold Separately)
- Factory Warranty: 2 years. Warranty Begins on Date of Purchase.
Note: If using a power source other than the Torqeedo 24-3500 Power Battery to power your Cruise, the actual percentage remaining, the remaining range and the runtime will be estimated. Only a Torqeedo Power Battery will communicate with your motor to give real time information.
-
€3,951.00
Description
Features:
- Aluminum Reinforced Fixed Position Pod Drive, Robust Design
- Recommended for Sailboats up to 6 tons
- Gas Outboard Equivalent: 9.9 HP
- Forward/Neutral/Reverse drive
- Onboard Computer and Display with GPS-Calculated range and runtime
- When used in combination with a Torqeedo Power Battery you get a Real Time Display of Speed, Input Power, Exact Battery Status and Remaining Range
- Operates with Lithium or AGM/Lead-Gel Batteries (Sold Separately)
- TorqLink Data Interface – enables fast data exchange between TorqLink components without gateway
Specifications:
- Engine Type: Electric – 48V
- Remote (Remote Throttle Not Included)
- Weight: 32.4 lbs
- Power Cable: 4.4 Meters
- Gas Outboard Equivalent: 9.9 HP (Propulsive Power)
- Gas Outboard Equivalent: 15 HP (Thrust)
- Propulsive Power in Watts: 2,760
- Static thrust: 230 lbs
- Torqeedo static thrust measurement is based on internationally accepted ISO standards. Static thrust figures for conventional trolling motors are typically measured differently, which results in higher values. To compare Torqeedo static thrust data with conventional trolling motors, add approximately 50% to the Torqeedo static thrust values
- RPM Range: Variable to 1,130
- Standard Propeller: 3 Blade fiberglass reinforced polyamide
- Waterproof (IPx9K outside the hull when completely assembled)
- Requires 48V DC
- Can be powered by (2) Torqeedo Power 24-3500 or (1) 48-5000
- External Battery(s) are not included with this model
- This model does not use an Internal battery
- Optional Folding Propeller (Sold Separately)
- Factory Warranty: 2 years. Warranty Begins on Date of Purchase.
Note: If using a power source other than the Torqeedo 24-3500 (x2) or 48-5000 Power Battery to power your Cruise, the actual percentage remaining, the remaining range and the runtime will be estimated. Only a Torqeedo Power Battery will communicate with your motor to give real time information.
-
€3,600.00
Description
Features:
- Can be used in place of (2) 24V DC power sources with Cruise 4.0, 6.0, 10.0 and 12.0 motors (48V DC)
- Battery management system has integrated protection against overcharging, short circuit, deep discharge, polarity reversal, overheating and submersion
- Waterproof: IP67
- Warranty: 2 years for non-commercial use
Specifications:
- Rated Voltage: 44.4V
- Useable Capacity: 5,275W Hours
- Weight: 36.5kg (80.5 lbs)
- Dimensions (L x H x B): 506 mm x 224 mm x 386 mm (19.9″ x 8.8″ x 15.2″)
- Battery Chemistry: LMO-NMC
- 10hr Charge time with optional 650W charger
- Cycle Lifetime: >3,000 cycles with 80% discharge depth at 25° celsius – results in approximately 20% capacity loss
In the Box:
- Power 48-5000 high-performance lithium battery 5,000W hours (44.4 V)
- Cable for communication with TQ- CAN
Note: Gateway TQ-Bus/TQ-Can and On/Off Switch for Power 48-5000:
- At the start of production for the Power 48-5000, Cruise 4.0 and 10.0 motors will be compatible with the new battery
- Power 48-5000 can be operated and switched on and off with the switch included in the scope of delivery of the new throttles part no. 1949-00, 1950-00, 1951-00 and 1952-00. The gateway is also included in the scope of delivery of the new throttles
- A separate gateway including the on/off-switch (part no. 2217-00) is required, if Power 48-5000 is used with standard Cruise models and their standard tillers and throttles
- A separate on/off-switch (part no. 2215-00) is required, if Power 48-5000 is used with non Torqeedo consumers
Note: Due to the technical nature of this product, this item is not returnable.
-
€2,700.00
Description
Features:
- Aluminum Reinforced Pylon with Integral Fin
- Gas Outboard Equivalent: 6 HP
- Forward/Neutral/Reverse drive
- Integrated magnetic on/off switch
- Multifunction display (battery charge, range, speed, current input power)
- Manual Tilt with Grounding Protection
Specifications:
- Engine Type: Electric – 24V
- Shaft Length: 24.6″ or 29.7″
- Remote Steering (Remote Throttle Not Included)
- Weight:
- 24.6″ Shaft: 41.7 lbs
- 29.7″ Shaft: 42.8 lbs
- Power Cable
- Gas Outboard Equivalent: 6 HP (Propulsive Power)
- Gas Outboard Equivalent: 8 HP (Thrust)
- RPM Range: Variable to 1,100
- Standard Propeller: 3 Blade fiberglass reinforced polyamide (B 12″ x 10.5″ WDR)
- Factory Warranty: 2 years. Warranty Begins on Date of Purchase.
Note: If using a power source other than the Torqeedo 24-3500 Power Battery to power your Cruise, the actual percentage remaining, the remaining range and the runtime will be estimated. Only a Torqeedo Power Battery will communicate with your motor to give real time information.
-
€3,227.00
Description
Features:
- Aluminum Reinforced Pylon with Integral Fin
- Gas Outboard Equivalent: 9.9 HP
- Forward/Neutral/Reverse drive
- Integrated magnetic on/off switch
- Multifunction display (battery charge, range, speed, current input power)
- Manual Tilt wth Grounding Protection
Specifications:
- Input power: 6000W
- Propulsive power: 3504W
- Comparable petrol outboards (propulsive power): 9.9 HP
- Comparable petrol outboards (thrust): 15 HP
- Maximum overall efficiency in: 58%
- Static thrust: 230 lbs
- Nominal voltage: 48V
- Standard propeller: Propeller B 12.5 x 17 HSP
- Maximum propeller speed: 1130 RPM
- Control: Remote throttle
- TorqLink: Yes
- Tilting device: Manual with grounding protection
- Tilt angle: 360 deg. lockable
- Trim device: Manual, 4-step
- Integrated on-board computer: Yes
- Stepless forward/reverse drive: Yes
- Shaft: 24.6″ or 29″
- Weight:
- 24.6″ Shaft: 45.4 lbs
- 29″ Shaft: 46.3
- Power Cable
- Factory Warranty: 2 years. Warranty Begins on Date of Purchase.
Note: If using a power source other than the Torqeedo 24-3500 or 48-5000 Power Battery to power your Cruise, the actual percentage remaining, the remaining range and the runtime will be estimated. Only a Torqeedo Power Battery will communicate with your motor to give real time information.
-
€2,655.00
Description
Features:
- Aluminum Reinforced Pylon with Integral Fin
- Gas Outboard Equivalent: 6 HP
- Forward/Neutral/Reverse drive
- Integrated magnetic on/off switch
- Multifunction display (battery charge, range, speed, current input power)
- Manual Tilt with Grounding Protection
Specifications:
- Engine Type: Electric – 24V
- Shaft Length: 24.6″ or 29.7″
- Remote Steering (Remote Throttle Not Included)
- Weight:
- 24.6″ Shaft: 41.7 lbs
- 29.7″ Shaft: 42.8 lbs
- Power Cable
- Gas Outboard Equivalent: 6 HP (Propulsive Power)
- Gas Outboard Equivalent: 8 HP (Thrust)
- RPM Range: Variable to 1,100
- Standard Propeller: 3 Blade fiberglass reinforced polyamide (B 12″ x 10.5″ WDR)
- Factory Warranty: 2 years. Warranty Begins on Date of Purchase.
Note: If using a power source other than the Torqeedo 24-3500 Power Battery to power your Cruise, the actual percentage remaining, the remaining range and the runtime will be estimated. Only a Torqeedo Power Battery will communicate with your motor to give real time information.
-
€3,229.00
Description
Features:
- Aluminum Reinforced Pylon with Integral Fin
- Gas Outboard Equivalent: 9.9 HP
- Forward/Neutral/Reverse drive
- Integrated magnetic on/off switch
- Multifunction display (battery charge, range, speed, current input power)
- Manual Tilt with Grounding Protection
Specifications:
- Input power: 6000W
- Propulsive power: 3504W
- Comparable petrol outboards (propulsive power): 9.9 HP
- Comparable petrol outboards (thrust): 15 HP
- Maximum overall efficiency: 58%
- Static thrust: 230 lbs
- Nominal voltage: 48V
- Standard propeller: Propeller B 12,5 x 17 HSP
- Maximum propeller speed: 1130 RPM
- Control: Tiller
- Steering: 360 deg. lockable
- Tilting device: Manual with grounding protection
- Tilt angle: 61.3 deg.
- Trim device: Manual, 4-step
- Integrated on-board computer: Yes
- Stepless forward/reverse drive: Yes
- Weight:
- 24.6″ Shaft: 47.0 lbs
- 29.7″ Shaft: 48.1 lbs
- Power Cable
- Factory Warranty: 2 years. Warranty Begins on Date of Purchase.
Note: If using a power source other than the Torqeedo 24-3500 or 48-5000 Power Battery to power your Cruise, the actual percentage remaining, the remaining range and the runtime will be estimated. Only a Torqeedo Power Battery will communicate with your motor to give real time information.
-
€2,700.00
Description
Features:
- Aluminum Reinforced Pylon with Integral Fin
- Gas Outboard Equivalent: 6 HP
- Forward/Neutral/Reverse drive
- Integrated magnetic on/off switch
- Multifunction display (battery charge, range, speed, current input power)
- Manual Tilt w/ Grounding Protection
Specifications:
- Input power: 3000W
- Propulsive power: 1530W
- Comparable petrol outboards (propulsive power): 6 HP
- Comparable petrol outboards (thrust): 8 HP
- Maximum overall efficiency: 0.51
- Static thrust in lbs : 142 lbs
- Integrated battery: No
- Nominal voltage: 24V
- Shaft length in cm: 62.5 (S) / 75.5 (L)
- Standard propeller: B 12 x 10,5 WDR
- Maximum propeller speed in rpm: 1100 RPM
- Control: Remote throttle
- TorqLink: No
- Steering: Provision to connect to standard remote steering; lockable
- Tilting device: Manual with grounding protection
- Tilt angle: 61.3 deg.
- Trim device: Manual, 4-step
- Integrated on-board computer: Yes
- Stepless forward/reverse drive: Yes
- Weight:
- 24.6″ Shaft: 43.4 lbs
- 29.7″ Shaft: 44.5 lbs
- Power Cable
- Factory Warranty: 2 years. Warranty Begins on Date of Purchase.
